RF4 RF-7050TV+2KC2PRO+S010 Trinocular Electronic Repair Microscope 2K Camera 10 Inch Display 7X-50X Zoom 144 LED for PCB Soldering
Rate: ( 0 reviews ) views: 62
Item No.: 6616001983A Ships in 1 - 3 days MOQ: 1
| 1+ units | 2+ units | 4+ units | 5+ units | 10+ units | 20+ units |
| $313.94 | $311.33 | $308.71 | $306.09 | $303.48 | $300.86 |
Contact Sales Manager
- [email protected]
- Ipartsexpert - Ada Shi
+86 - 18620397679
Specifications
- Brand :RF4
- Color :As Shown
- Gross Weight :7.728kg
- Volume Weight :12.277kg
- Length :54.000cm
- Width :35.000cm
- Height :29.000cm
- Weight :6.900kg
- EAN :
- PackageLength :59.000cm
- PackageWidth :40.000cm
- PackageHeight :35.000cm
- PackageQuantity :1
- With Retail Packaging :No
Product Description
RF4 RF-7050TV+2KC2PRO+S010 Trinocular Electronic Repair Microscope 2K Camera 10 Inch Display 7X-50X Zoom 144 LED for PCB Soldering
- 【Trinocular Stereo Microscope System】Professional RF-7050TV stereo microscope with dual eyepiece observation and integrated 2K Ultra HD industrial camera for simultaneous visual and digital inspection.
- 【Continuous 7X-50X Magnification】Variable zoom magnification from 7X to 50X with optional Barlow lenses (0.5X, 0.7X, 2.0X) for enhanced magnification flexibility in precision repair work.
- 【2K Ultra HD Digital Imaging】Integrated 2KC2PRO industrial camera delivers ultra-high-definition 2K resolution for crystal-clear digital documentation and analysis.
- 【10-inch External Display Monitor】Dedicated HD/VGA input monitor provides real-time enlarged images, enabling detailed inspection of electronic components and circuit boards.
- 【144 LED Ring Illumination】Professional S010 adjustable LED ring light with 144 LED bulbs provides uniform, shadow-free illumination for optimal viewing conditions.
- 【360° Rotating Head Design】45-degree tilted trinocular head with 360-degree rotation capability allows comfortable viewing angles and flexible positioning for various inspection tasks.
Specifications:
- Model: RF-7050TV+2KC2PRO+S010
- Magnification Range: 7X-50X Continuous Zoom
- Head Design: 45° Tilted, 360° Rotation Trinocular
- Eyepiece: WF10X/22mm
- Barlow Lens: 0.5X & 0.7X & 2.0X (Optional)
- Objective: 0.7-5.0X
- Camera Connector: 0.5X CTV
- Resolution: 2K Ultra HD
- Display: 10 inch HD/VGA Input
- LED Illumination: 144 Adjustable LED Ring Light
- Boom Stand: 250mm φ32mm Post with Standard Base
Package included:
- 1 x Microscope Camera
- 1 x HD Port
- 1 x USB Cable
- 1 x English and Chinese User Manual
- 1 x Power Cord
- 1 x Remote Control
- 1 x Microscope Main Unit
- 1 x Display Screen
- 1 x Stand
- 1 x 0.5X CTV
- 1 x 144 LED Light
- 1 x Dustproof Mirror
